step 6: attach the side panels and partition panel to the top panel
(H1) x 6
cam lock
(H3) x 6
M8 x 30 mm wood dowel
6.1. Insert six wood dowels (H3) into the top inner holes of both side panels (D) and the partition panel (E).
6.2. Orient and attach the side panels (D) and partition panel (E) to the top panel (A) using six cam locks (H1).
A
H1
H3
D
D
E
A
D
E
12
The pilot holes for door hinges face inward
and are located at front of the unit.
