Throwdown HIIT UBE - Page 8

Page 8
6. Place the Bench (720-5175-XX) on
the Bench Mounts (720-5179).
720-5179720-5175-XX
Fig. 8
7. Insert 4 AA batteries into console
from package and close back
cover.
8. Align the Console (020-8167)
against the Mounting Plate
(716-0276-XX) and secure it with
four M5 Button Head Cap Screws
(110-3641).
9. Plug the Console Cable (718-5731)
into the Console (701-0541).
718-5731
110-4446
716-0276-XX
701-0541
Fig. 9
10. Assembly is Complete. Proceed to
First-Time Setup on the next page.
Fig. 10
