Page 7
4. Install the Tread Plate (720-5102)
with two M5 Flat Head Machine
Screws (110-3603).
720-5102
110-3603
Fig. 6
5. Align the Left Handle (720-5192-
XX) against the Left Crank Arm
(720-5172-XX-KT) and install with
an M8 Axle Screw (740-8145).
Note: Only the Left Handle needs
installed.
740-8145
720-5192-XX
720-5172-XX-KT
Fig. 7
To Next Page
