THRUSH S2R-H80 - Page 18

S2R-H80 Single & Dual Cockpit
AIRPLANE FLIGHT MANUAL
AFM H8001 SINGLE & DUAL COCKPIT Revision B Page 4
FAA APPROVAL DATE: 3/19/2015
LIMITS
FEATURES
MEANING
OIL TEMP (°C)
-20
RED Radial
Minimum
-20 to +20
YELLOW Arc
Caution Range
20 to 85
GREEN Arc
Normal Range
85
RED Radial
Maximum
OIL PRESSURE (PSI)
18
RED Radial
Minimum
18 to 26
YELLOW Arc
Caution Range
26 to 39
GREEN Arc
Normal Range
39 to 49
YELLOW Radial
Caution Range
49
RED Radial
Maximum
FUEL PRESSURE (PSI)
12.5
RED Radial
Minimum
12.5 to 34.0
GREEN Arc
Normal Range
34.0
RED Radial
Maximum
ITT (°C)
0 to 750
GREEN Arc
Normal Range
750-780
YELLOW Arc
Caution Range
780
RED Radial
Maximum
TORQUE (%)
0 to 100
GREEN Arc
Normal Range
100 to 106
YELLOW Arc
Caution Range
106
RED Radial
Maximum
PROP RPM (N
P
)
0 to 400 RPM
GREEN Arc
Normal Range
400 to 1100 RPM
YELLOW Arc
Caution Range
1100 TO 2080 RPM
GREEN arc
Normal Range
2080 TO 2140 RPM
YELLOW arc
Caution Range
2140 RPM
RED Radial
Maximum
GAS GEN SPEED
(N
G
)
0 to 100.1
GREEN Arc
Normal OP Range
100.1 – 101.5
YELLOW Arc
Caution Range
101.5
RED Radial
Maximum
AIRSPEED
MPH
88 to 157
WHITE Arc
Flap Operating Range
94 to 158
GREEN Arc
Normal Operating Range
159 to 186
YELLOW Arc
Caution Range
>186
RED Line
Never Exceed
