S2R-H80 Single & Dual Cockpit
AIRPLANE FLIGHT MANUAL
AFM H8001 SINGLE & DUAL COCKPIT Revision B Page 20
FAA APPROVAL DATE: 3/19/2015
2.2. MVP-50T GLASS PANEL ENGINE MONITORING SYSTEM
MVP-50T MAIN SCREEN
PROCEDURES
The MVP-50T Main Engine Screen displays the primary engine and aircraft instruments,
but not flight instruments. This screen is displayed on electrical power-up and should be
monitored throughout the flight.
Buttons operate as follows:
EXIT: Exits out of a field or screen, returns the display to the Main
Screen and acknowledges blinking cautions and warnings.
Press and hold EXIT for three seconds to test the
annunciators. Annunciators will be displayed in the color of
the individual parameter’s current reading.
SCREENS: Switches the display between screens as selected in the
Screens Button Setup.
MENU: Displays a menu (if available) for the current screen.
PUSH-SELECT: Moves the cursor, selects functions and changes digits.
