10/17
Installing the SPRING BRAKE MOD (18)
This mod allows for different sensations and resistance when braking.
Users must decide whether or not to install it according to their own preferences.
- Install the SPRING BRAKE MOD (18) fully and tightly into the bottom of the cavity in the metal
stop (23).
- For strong resistance: position the mod against the upper wall.
- For even stronger resistance: position the mod against the lower wall.
Position against the upper wall Position against the lower wall
(resistance of approx. 30.9 lbs / 14 kg) (resistance of approx. 35.2 lbs / 16 kg)
- Once this is done, attach the metal stop (23) behind the pedal’s arm with the 4 M3-type Allen
screws (8), using the included 2.5 mm Allen key (20).
Position against the upper wall Position against the lower wall
(resistance of approx. 30.9 lbs / 14 kg) (resistance of approx. 35.2 lbs / 16 kg)
Important note:
To avoid any calibration problems, the SPRING BRAKE MOD must only be installed
in the Long range of travel position
(i.e. do not install it in the Medium range or Short range of travel positions)
