ATTACHING HOLD FAST ANTI-SWAY CAGES
• To attach anti-sway cage, hold horizontal with smooth edge facing down and slide C-slot opening onto Anti-Sway Extension / Cradle. Swing down to vertical position.
Place smooth curved surface against bicycle and attach strap as shown.
• Mount bikes in alternate directions.
A B
9
• Secure bikes to mast of carrier with black strap.
10
REAR COMPARTMENT ACCESS /
• Loosen lower locking
handle completely
and pull pin to open
carrier.
• While pushing bottom half of bike
arm assembly open, rotate upright
assembly as illustrated. In full open
position lock-up pin will engage
bracket.
A B
lock-up pin
broche de verrouillage
pasador de cierre
lower locking handle
poignée de
verrouillage inférieure
asa inferior de cierre
