11
OPENING CARRIER /
• Insert hold-open pin into locking position when fully open to prevent carrier from swinging closed.
hold-open pin
A
B
12
CLOSING CARRIER /
• Pull Lock-up pin to release upper arm assemby and
rotate bike arms to stop position.
• Close carrier. Lock-up pin will click into
closed position.
• Tighten lower locking handle firmly.
WARNING: Before operating
your vehicle, tighten
locking handle firmly.
A
B
lower locking handle
lock-up pin
