7) LOAD CELL
Limits of the Load Cell
The Load Cell may not be deformed more than max. 0.2 mm in pulling
direction!
Doing pressure tests, ensure that the Load Cell does not bend out to the side!
Low force Load Cells: There is a high risk of damage by permanent bending,
which is due to the Load Cells construction principle.
In case there is a danger of Load Cell Overload, we recommend using special
protection equipment.
After overload damage, the Load Cell may still show measurements, but is not
linear anymore.
To ensure the accuracy of a Load Cell a calibration test should be done with
multiple different weights.
If necessary adjust the calibration factor.
We only can provide the Load Cell Function as guaranteed by the
manufacturer.
Any warranty claims which are due to male operation or overload will not be
accepted.
Zero adjustment
By pressing "0" before testing a Zero adjustment is done.
As the clamping of probes does already produce forces, a Zero adjustment
should be always done before testing.
