THUNDER TIGER MD500 - Parts Check List

6
PARTS CHECK LIST
Missile Set
Wing (L,1)
Wing (R,1)
Missile Pod (2)
Pod Retainer (L,1)
Pod Retainer (R,1)
Ring(2)
Joiner (2)
Vent (4)
3x25mm Wood Screw (2)
3x15mm Wood Screw(4)
2x8mm Wood Screw(8)
2x5mm Wood Screw(12)
Body Retainer
Post (L,2 )
Post (S,2)
Set Screw(L,2)
Set Screw(S,2)
Damper (L,2)
Damper (S.2)
M3 Locknut (2)
Windshield
Front Windshield (1)
Right Front Window (1)
Kit Contents:
Fuselage
Fuselage (1)
Missile Sight (1)
Round Plywood (S,2)
Round Plywood (L,2)
Laser Range Finder (1)
FLIR (infrared) (1)
Tail Boom Foam Retainer (1)
M4 Washer (4)
Silicon Grommet (4)
Strut Rubber (4)
2 x5mm Wood Screw (10)
Plastic Tube (1)
Fiberglass Cloth (1)
Tail Set
Vertical Fin (1)
Horizontal Tail (1)
Tip Fin (2)
3x 40 mm Socket Screw (2)
3x18mm Wood Screw (2)
3x8mm Wood Screw (4)
M3 Washer (4)
M3 Locknut (2)
Left Front Window (1)
Right Rear Window (1)
Left Rear Window (1)
Right Top Window (1)
Left Top Window (1)
Missile Sight Lens (1)
2x5 mm Machine Screw (16)
M2 Nut (16)
2x5 mm Wood Screw (48)
Mask Tape (1)
Landing Skid
Brace (2)
Al.Strut (4)
Skid Joiner (R,2)
Skid Joiner (L,2)
End Cap (4)
3x 30 mm Socket Screw (4)
3x3mm Set Screw (4)
2.6x 14mm Self Tapping Screw (8)
2.6x10mm Self Tapping Screw (4)
M3 Locknut (4)
Rear Frame Set
Rear Frame (L,1)
Rear Frame (R,1)
Washer (4)
