11
a. Check the radio throttle/brake functions. With the radio transmitter and receiver on, pull the trigger/push
the stick forward. The carburetor should be fully opened and the brake disengaged. To reverse this
function, flip the throttle/brake servo reverse switch.
b. Return the trigger/stick to neutral. The carburetor should be closed to a point where the idle has been
set (see step for ADJUSTING THROTTLE/BRAKE LINKAGE), and the brake still disengaged. If not,
use the throttle/brake trim lever to correct it.
c. Push the trigger/pull the stick backward. The carburetor opening should still be the same at neutral,
throttle spring compressed slightly, and the brake engaged.
d. Press the Forward/Reverse Button. This will shift the truck into Reverse. Press the Forward/Reverse
Button again to shift the truck into Forward.
OPERATING RADIO THROTTLE / BRAKE
AND REVERSE FUNCTION
7
abc
c
d
