Parts No. Description Item No. Description quantity Reference
Assemble Step
Parts No. Description Item No. Description quantity Reference
Assemble Step
45
Parts No. Description Item No. Description quantity Reference
Assemble Step
42
Parts No. Description Item No. Description quantity Reference
Assemble Step
43
Parts No. Description Item No. Description quantity Reference
Assemble Step
44 46
47
NO. 3803 REMOTE GLOW
ADAPTER
NO. 3800 BLADE SUPPORT NO. 3801 6MM STARTER
EXTENSION
NO. 3802 PRECISION
PITCH GAUGE
PV0092 SWASHPLATE PV0099 CARBON TAIL BOOM PV0102 HIGH PERFORMANCE
MUFFLER (.36/.39)
PV0109
HIGH PERFORMANCE
MUFFLER (.46~.50)
PV0108 R50 TAIL BOOM
PV0311 HEADER TANK PV0321 REAR MOUNTED TAIL
SERVO TRAY
PV0379 AUTO-R TAIL PULLY PV0380 PINION GEAR 10T PV0384 WIRE CLAMP
PV0054 SERVO MOUNTING
PLATE
PV0103 CARBON TAIL BOOM
BRACE
PV0104 ALUMINUM FRAME
POST
PV0107 ENGINE MOUNT (.50)PV0105 COOLING FAN (.36)
PV0106 COOLING FAN (.50)
NO.3831 Raptor 30 V2 Crash Kit
PV0392 R50 TAIL CONTROL ROD
PV0387 THROTTLE LEVER
PV0390 R50 CARBON TAIL BOOM
PV0394 CARBON FIBER-LOOK
CANOPY
48
PV0439 METAL TAIL PITCH SLIDER
PV0439-L METAL TAIL PITCH SLIDER (BL)
PV0399 MAIN ROTOR GRIP POST
PV0443 STABILIZER CONTROL
SET
PV0441 METAL ELEVATOR
LEVER SET
PV0442 METAL MIXING LEVER
SET
PV0444 FLYBAR CONTROL
ARM SET
PV0445 METAL WASHOUT
ASSEMBLY
PV0446 METAL AILERON LEVER
SET
PV0447 ELEVATOR ARM LINK PV0448 SOCKET LINK BALL
SCREW
PV0449 ROTOR GRIP PLATE SET
PV0451 HARDENED MAIN SHAFT
PV0482 ULTRA LIGHT PADDLE
PV0349 PUSH/PULL ELEVATOR
LEVER SET
PV0326 CARBON GRAPHITE
BASE PLATE
PV0338 METAL MAIN ROTOR HUB
FOR V2
PV0339 METAL MAIN ROTOR GRIP
FOR V2
PV0440 METAL FRAME
SPACER(S)
PV0450 SUS FLYBAR ROD
PV0481 LIGHT FLYBAR PADDLE PV0483 CARBON TAIL FIN SE
T
PV0484 METAL BUTTON
ROTOR HUB
PV0485 R50 SE DECAL
NO. 8071 TG7000, DS0606
NO. 8130 DIGITAL RUDDER SERVO,
DS0606
NO. 8126 DIGITAL SERVO, DS1213
NO. 8070 HEADING LOCK GYRO,
TG7000
PV0114 METAL WASHOUT BASE
PV0345 R30 REAR SERVO ROD
PV0346 R50 REAR SERVO ROD
PV0356 60 DUROMETER FLAP DAMPER
PV0382 80 DUROMETER FLAP DAMPER
PV0499 SUS TAIL HUB
NO. 8030 ZERO
α
GOVERNOR
AK0029 Main Shaft BK0029 Main Shaft 1 7
AK0031 Main Spur Gear BK0031 Main Spur Gear 1 4
AK0032 Tail Drive Pulley BK0032 Tail Drive Pulley 1 4
AK0060 Tail Boom BK0060 Tail Boom 1 14
AK0089 Tail Dirve Belt BK0089 Tail Dirve Belt 1 14
AV0038 Cooling Fan Assy. BV0038 Cooling Fan Assy. 1 9
AV0052 Tail Idel Pulley Assy. BV0052 Tail Idel Pulley 1 14
No.9219 Muffler BN219 Muffler 1 10
PV0002 Flybar Arm BK0002 Flybar Control Arm 2 11
BK0005 Flybar Arm Bushing 2 11
BK0075 Linkage Ball 2 11
HME4-5B Set Screw, M4x5 2 11
HMJ2-10N Selftapping Screw, M2x10 2 11
PV0004 Mixing Lever BK0006 Mixing Lever 2 11
BK0075 Linkage Ball 4 11
BK0076 Collar (dxD4xL10) 2 11
BK0088 Flat Washer 2 11
HMC3-14B Socket Screw, M3x14 2 11
HMJ2-10N Selftapping Screw, M2x10 4 11
PV0005 Flybar Control Rod BK0007 Flybar Control Rod 2 11
PV0008 Flybar Rod BK0010 Flybar Rod 2 11
PV0011 Washout Set BK0014 Washout Base 1 5
BK0015 Flyber Control Lever 1 5
BK0016 Washout Linkage 2 5
BK0075 Link Ball 2 5
BK0077 Collar (d3xD4xL6) 2 5
BK0079 Pin 2 5
HMC3-10B Socket Screw, M3x10 2 5
HMJ2-10N Selftapping Screw, M2x10 2 5
PV0012 Pitch Control Arm BK0017 Pitch Control Arm 1 6
BK0075 Link Ball 1 6
BK0078 Collar (d3xD4xL4) 2 6
HMJ2-10N Selftapping Screw, M2x10 1 6
HMJ3-22B Selftapping Screw, M3x22 1 6
HSE3-12B Selftapping Screw, M3x12 1 6
PV0013 Elevator Arm BK0018 Elevator Control Arm 1 6
BK0019 Elevator Arm Parallel Lever 1 6
BK0020 Elevator Arm Shaft 1 6
BK0023 Elevator Arm Linkage 2 6
BK0075 Linkage Ball 1 6
BK0084 Pin (D2xL23) 2 6
HMJ2-10N Selftapping Screw, M2x10 1 6
HSE3-18B Selftapping Screw, M3x18 2
6
PV0014 Elevator Lever BK0021 Elevator Control Lever 1 6
BK0075 Linkage Ball 2 6
BK0076 Collar (d3xD4xL10) 1 6
BK0088 Flat Washer 1 6
HMJ2-14N Selftapping Screw, M2x14 1 6
PV0015 Aileron Lever BK0022 Aileron Control Lever 2 6
BK0075 Linkage Ball 4 6
BK0076 Collar (d3xD4xL10) 2 6
HMJ2-10N Selftapping Screw, M2x10 4 6
HSE3-18B Selftapping Screw, M3x18 2 6
PV0016
Tail Pitch Control Lever
BK0024 Tail Pitch Control Lever 1 13
BK0075 Linkage Ball 1 13
BK0076 Collar (d3xD4xL10) 1 13
BK0088 Flat Washer 1 13
HMJ2-8N Selftapping Screw, M2x8 1 14
HSE3-18B Selftapping Screw, M3x18 1 13
PV0017 Tail Pitch Slider BK0025 Tail Pitch Control Fork 1 13
BK0026 Tail Pitch Control Linkage 2 13
BK0027 Tail Pitch Control Slider 1 13
BK0028 Tail Pitch Control Slide Bushing 1 13
BK0075 Linkage Ball 1 13
BK0082 Collar, d2xD3xL4 2 13
BK0083 Pin, D2xL9 2 13
HMF2-8N Screw, M2x8 1 13
HSE2-10B Selftapping Screw, M2x10 2 13
PV0018 Main Shaft Lock Ring BK0030 Main Shaft Lock Ring 1 7
HME4-5B Set Screw, M4x5 2 7
PV0019 One Way Clutch BV0033 One Way Clutch Housing Set 1 4
HMC3-12 Socket Screw, M3x12 4 4
PV0020 One Way Clutch Shaft BK0034 One Way Clutch Shaft 1 4
HMC3-20B Socket Screw, M3x20 1 15
HMM3Z Lock Nut, M3 1 15
HMQ14 Retaining Ring, ø14 2 4
PV0021 Gudie Pulley Assy BV0035 Guide Pulley 1 3
BK0036 Pulley Collar 2 3
BK0081 Pin, D13xL18 1 3
PV0022 Engine Mount BK0037 Engine Mount 1 10
BK0087 Flat Washer 4 10
HMC3-14B Socket Screw, M3x14 8 10
PV0027 Tail Case BK0046 Tail Unit Housing (L) 1 14
BK0047 Tail Unit Housing (R) 1 13
HMC3-20B Socket Screw, M3x20 4 14
HMC3-25B Socket Screw, M3x25 2 14
HMM3Z Lock Nut, M3 6 14
PV0029 Tail Pulley Set BK0050 Tail Pulley Set 1 13
BK0051 Tail Pulley Flange 1 13
BK0414 Pin, D2xL12 1 13
HME3-4B Set Screw, M3x4 1 13
PV0030
Tail Rotor Shaft BK0053 Tail Rotor Shaft 1 13
BK0414 Pin, D2xL12 1 13
HME3-4B Set Screw, M3x4 1 13
PV0033 Servo Frame BK0057 Servo Frame 1 3
HMJ3-12B Selftapping Screw, M3x12 6 3
PV0035 Landing Skid Set BK0064 Skid 2 8
BK0065 Skid Cap 4 8
BK0066 Skid Brace 2 8
HMJ3-18B Selftapping Screw, M3x18 4 8
HME4-5B Set Screw, M4x5 4 8
PV0036 Flybar Paddle BK0067 Flybar Paddle 2 11
HME3-10B Set Screw, M3x10 2 11
PV0037 Tail Rotor Blade BK0068 Tail Rotor Blade 2 15
PV0038 Tail Fin BK0069 Stabilizer Fin 1 14
BK0070 Stabilizer Fin Bracket 1 14
BK0071 Vertical Fin 1 14
HSE3-12B Selftapping Screw, M3x12 2 14
PV0039 Main Rotor Blades BV0072 Main Rotor Blades 2 20
PV0040 Double Link BV0085 Double Link 2 11
PV0041 Ball Link BK0086 Ball Link 12 6
PV0043 Tail Control Rod BK0086 Ball Link 2 17
BK0091 Rod Guide 3 14
BK0105 Tail Control Rod Joint 1 16
BK100-1 Pulley Pull Rod-1 1 16
BK100-2 Pulley Pull Rod-2 1 14
HME4-5B Set Screw, M4x5 2 16
PV0044 Link Rod BK0092 Linkage Rod (L=30) 3 17
BK0093 Linkage Rod (L=45) 3 16
BK0094 Linkage Rod (L=60) 2 16
BK0095 Linkage Rod (L=76) 2 12
PV0048
Pitch Frame/
HMV840ZZ Bearing, d4xD8xW3 2 6
Rotor Hub Seesaw Brg.
PV0049 Seesaw Brg. HMV830ZZ Bearing, d3xD8xW4 2 11
PV0051 Leaver Brg. HMV740ZZ Bearing, d4xD7xW2.5 4 6
PV0052 Tail Slider Brg. HMV1060 Bearing, d6xD10xW3 2 13
PV0053 Rotor Bolt. HMC4-27B Cap Screw, M4x27 2 20
HMM4Z Lock Nut, M4 2 20
PV0056 Frame Spacer (L) BK0058 Frame Spacer (L) 5 3
PV0057 Frame Spacer (S) BK0059 Frame Spacer (S) 10 3
PV0058 Link Ball BK0075 Linkage Ball 12 13
PV0059 Tail Shaft HMV1150 Bearing, d5xD11xW 2 13
PV0060 Installation Set BE1052 Antenna Tube 1 18
BK0106 Double Side Tape 2 18
BK0109 Rubber Band 5x3 20xT1 2 18
HNI15 Hex Wrench 1.5m/m 1 1
HNI2 Hex Wrench 2m/m 1 1
HNI25 Hex Wrench 2.5m/m 1 1
HNI3 Hex Wrench 3m/m 1 1
HNJ-1 Tie Band 2.5x10
0 3 8
PV0062
Body Mount Rubber Grommet
BK0102 Body Mount Rubber 5 19
PV0063 Bushing Set BK0108 Bushing (d4xD8xW2.5) 2 8/11
PV0064 Lever Bushing
BK0107 Bushing (d4xD7xW2.5) 4 7/8/11/12
PV0088 Screw Bag HMF2-6N Screw, M2x6 6
HMF2-8N Screw, M2x8 6
HMJ2-10N Selftapping Screw, M2x10 6
HMJ2-14N Selftapping Screw, M2x14 6
HMJ2-6B Selftapping Screw, M2x6 6
HMJ3-22B Selftapping Screw, M3x22 6
HSE2-10B Selftapping Screw, M2x10 6
HSE2612N Selftapping Screw, M2.6x12 6
HSE3-12B Selftapping Screw, M3x12 6
HSE3-18B Selftapping Screw, M3x18 6
HSE3-5B Selftapping Screw, M3x5 6
PV0089 Screw Bag BK0616 Socket Screw, M3x20 2
HMC3-10B Socket Screw, M3x10 6
HMC3-12B Socket Screw, M3x12 6
HMC3-14B Socket Screw, M3x140 6
HMC3-20B Socket Screw, M3x20 4
HMC3-25B Socket Screw, M3x25 6
HMC3-32B Socket Screw, M3x32 6
HMC3-8B Socket Screw, M3x8 6
HME3-10B Set Screw, M3x10 6
HME3-18B Set Screw, M3x18 6
HME4-5B Set Screw, M4x5 6
PV0091 Bearing Upgrate Kit HMV740ZZ Bearing, d4xD7xW2.5 16 5/6/11/13
HMV840ZZ Bearing, d4xD8xW2.5 4 6/11
PV0093 Main Shaft Bearing HMV1680 Bearing, d8xD16xW5 1 2
HMV6800 Bearing, d10xD19xW5 2 3
PV0148 Tail Rotor Grip BK0302-1 Tail Pitch Housing (A) 2 13
BK0303-1 Tail Pitch Housing (B) 2 13
HMC2610B Socket Screw, M2.6x10 4 13
HMM26B Lock Nut, M2.6 4 13
HMC3-14B Socket Screw, M3x14 2 14
HHM3B Lock Nut, M3 2 14
PV0151 Tail Rotor Hub BK0307 Tail Rotor Hub 1 13
HME3-18B Set Screw, M3x18 2 13
HMM3B Lock Nut, M3 2 13
PV0639 Tail Rotor Angular Bag HMV1050ZZO Bearing, d5xD10x4 4 8
PV0203 Starter Shaft Brg HMV696Z Bearing, d6xD15x5 2 3
PV0209 Washer Bag BK0435 Washer, d4xD11xt1.7 4 11
PV0210 Washer Bag BK0087 Washer, d3xD8xt1.4 16
10
PV0223 Screw Bag HMC4-8B Socket Screw 20 11
PV0267 Loctite #242 1
PV0268 Loctite #262 1
PV0269
Thrust Bearing Grease
1
PV0270 Plastic Gear Grease 1
PV0279 Tail Rod Guide BK0091 Rod Guide 3 14
PV0328 Tail Support BK0447 Tail Support Rod End 4 14
BK0540 Tail Support Rod 2 14
HMJ2-8N Selftapping Screw, M2x8 4 14
HSE3-12B Selftapping Screw, M3x12 4 14
PV0353 Main Rotor Grip BK0075 Linkage Ball 2 11
BK0596 Main Pitch Housing 2 11
HMJ2-10N Selftapping Screw, M2x10 2 11
PV0354 Main Rotor Hub BK0587 Main Rotor Pin 1 11
BK0616 Socket Screw, M3x20 1 11
BV0595 Main Rotor Hub 1 11
HMM3Z Lock Nut, M3 1 15
PV0355 Spindle BK0581 Flap Collar 2 11
BK0583 Feathering Shaft 1 11
BK0435 Washer, d4xD11x1.7 2 11
HMC4-8B Socket Screw, M4x8 2 11
PV0357 Swash Plate Assy BV0601 Swash Plate Assy 1 7
PV0358 Clutch Bell BV0591 Clutch Bell Set 1 2
PV0359 Clutch BK0170 Shim 1 9
BV0589 Clutch Bell Set 1 9
HMC3-10B Socket Screw, M3x10 2 9
PV0360 Starter Shaft BK0592 Starter Shaft 1 3
HME4-5B Set Screw, M4x5 2 3
HMS5 E-Clip 1 3
PV0361 Starter Coupling BK0594 Starter Coupling 1 3
HME4-5B Set Screw, M4x5 2 3
PV0363 Fuel Tank BV0605 Fuel Tank Set 1 1
PV0364 Body BK0098 Body Clip A 1 19
BK0099 Body Clip B 1 19
BK0102 Robber Groment 2 19
BK0611 Body 1 19
BK0612 Canopy 1 19
HMJ2-6B Self Tapping Screw 6 19
HSE3-12B Selftapping Screw, M3x12 2 19
PV0365 Thrust Brg. HMX0612 Thrust Bearing 2 11
PV0366 Decal JV0093 Decal 1 19
PV0367 Pinion Gear (9T) BK0593 Drive Gear 1 2
PV0368 Clutch Liner BK0590 Clutch Liner 2 2
PV0369
Canopy Only BK0612 Canopy 1 19
HMJ2-6B Self Tapping Screw, M2x6 6 19
PV0370 Body Only BK0098 Body Clip A 1 19
BK0099 Body Clip A 1 19
BK0611 Body 1 19
BK0102 Rubber Groment 2 19
HSE3-12B Self Tapping Screw, M3x12 2 19
PV0372 Thrust Collar BK0584 Thrust Collar 2 11
PV0373 Clutch Bell Brg HMV1260Y Bearing, d6xD12xw4 2 2
PV0374 Feathering Brg. HMV1360Z Bearing, d6xD13xw5 2 11
PV0375 Body Retaining Set BK0626 Body Mount Nut 2 12
HME3-18B M3x18 Set Screw 2 12
PV0376 Main Rotor Pin BK0587 Main Rotor Pin 1 11
PV0381 Flap Damper (70) BK0586 Flap Damper 2 11
PV0454 Skid Pipe Cap BK0065 Skid Pipe Cap 8 8
PV0486 Flybar Seesaw BK0004 Seesaw 1 11
PV0480 Main Frame Set BK0058 Frame Spacer (L) 4 3
BK0059 Frame Spacer (S) 8 3
BK0599 Main Frame Left Side 1 3
BK0600 Main Frame Right Side 1 3
HMC3-20B Socket Screw, M3x20 4 15
HMM3Z Lock Nut, M3 4 15
HSE3-12B Selftapping Screw, M3x12 24 3
HMV830ZZ BRG,d3xD8xw4 2 11
HELICOPTER ACCESSORIES
RAPTOR 30 V2 OPTIONAL PARTS
To Next Page
Loading...
Need help?
General
