7
MAIN FRAME ASSEMBLY
1
For the kit, parts are bagged according to each major assembly and are labeled "Bag A, Bag
B, etc." The heading for each assembly indicates which bag to open. As a good practice,
only open up the bag that you need for the particular assembly. Check the parts in that bag
against the parts list shown for each assembly as well as each sub-assembly to make sure
there are no missing parts. To prevent losing small hardware, please empty the small nuts
and bolts and parts into small plastic trays on your work table. At the end of each major
assembly, there should be no left over parts.
