THUNDER TIGER SLEDGE HAMMER S50 Parts Catalog

MTA4 V2 PARTS LIST
PD7214 SLIPPER SHAFT
主軸
PD7215 MAIN SPUR GEAR,
49T
主齒輪
PD7216 SLIPPER HARDWARE,
滑動套件
PD7217 SPUR GEAR HUB
主齒輪固定座
PD7218 SLIPPER FRICTION
RING
摩
擦片
PD7219 SLIPPER LINGING
PAD
限滑來令片
PD7220
SLIPPER HUB
限滑固定座
PD7221
DRIVE PINION SHAFT
傘齒心軸
PD7222
2 SPEED PINION GEAR
齒輪
18Tx23
T
PD7227 FRONT DRIVE
OUTPUT CUP
六角形傳動軸套
PD7226 BALL TYPE UNIVERSAL,
萬象傳動軸
PD7223
CENTER TRANS
BRACKET
補強板
PD7224 CENTER TRANS CASE
齒輪箱本體
PD7255 CTR TRANS PINS,
軸承銷
PD7229 FRONT DRIVE CVA
前中央萬象傳動軸
PD7230 REAR DRIVE OUTPUT
CUP
傳動軸套
PD7231 REAR CVA REBULID KIT
中央萬象傳動軸接合套件
PD7232 FRONT&REAR BUMPER
保險桿組
PD7233 FRONT BUMPER & BRACE
前防撞板&固定架
PD7234 REAR BUMPER & BRACE
後防撞板&固定架
PD7237 UNIVERSAL REBUILD KIT
萬向接合套件
PD7236 WHEEL HEX DRIVE(4)
六角輪穀轉換器
PD7256 WHEELIE WHEEL
翹頭滾輪
PD7228 FRONT CVA
REBULID KIT
中央萬象傳動軸接合套件
MTA4 V2 P.8
(2)

THUNDER TIGER SLEDGE HAMMER S50 Specifications

Weight and Dimensions

overall length	615 mm / 24.2 in
overall height	273 mm / 10.7 in
overall width	438 mm / 17.2 in
wheelbase	368 mm / 14.5 in
max ground clearance	108 mm / 4.25 in
front track width	436 mm / 17.2 in
rear track width	436 mm / 17.2 in
weight (RTR)	6200 g / 13.76 lb
wheel diameter	174 mm / 6.85 in
