Right Wing(1)Left Wing (1)
Fuselage (1)
Wing Joiner Tube (1)
CA Hinge (8)
Nylon Retaining Screw (2)
Fin/Rudder (1)
Stab./Elevator (1)
CA Hinge (6)
Elevator Torque Rod (1)
Carbon Landing Gear (L/1,R/1)
M3x12 mm (4)
3x10mm Socket Screw (4) M3 Lock Nut(4) 3mm Washer (4)
Wheel (2)
2.3x8mm
Wood Screw (2)
Elevator(1)
Aileron (2)
Rudder(1)
3X3mm Setscrew (4) M2 Washer (8)
M2 Nut (4)
EZ Connector (4)
Hex Wrench(1)
Control Horn (4)
3mm Collar (2)
Wheel (2)
2.3x8mm Wood Screw (4)
Canopy (1)
3X3mm Setscrew (2)
M3 Washer (2)
M3x21mm
Socket Screw (2)
M3 Lock Nut (2)
AS9127-03 Fuselage
AS9127-04
AS9128-03 Main Wing
AS9128-04
AS9129-03 Tail Set
AS9129-04
AS913 0-03 Cowling
AS9130-04
AS913 1-03Canopy
AS913 1-04
AS9132 Pushrod AS9133 Control Horn
AS9134 EZ Connector AS9135 Lite Wheel
AS9136 Carbon Landing Gear AS9137 Wheel Pant
AS9138 Tail Gear
Open the box and check that you have all the parts as shown below.
PARTS DRAWINGS PARTS DRAWINGS
4 5
Mounting Strip (1) Tail Gear (1) Tail Wheel (1) 2mm Collar (1)2.3x8mm (2)
3X3mm
Set Screw (1)
Hex Wrench(1)
Cowling(1)
Hex Wrench(1)
Velcro (1) Tie Belt (1)
Frame (1)
