5.2 Survey of Commands
Command Code
Type of Device TD
Product Name PN
Serial Number Device SD
Serial Number Head (Sensor) SH
Version Device VD
Version Firmware VF
Version Bootloader VB
Baud Rate BR
Response Delay RD
Device Restart DR
Measurement Range MR
Measurement Value MV
Display Unit DU
1
Display Orientation DO
1
Relay 1 R1
Relay 2 R2
Adjust High (Atmosphere Pressure) AH
Adjust Low (Zero Pressure) AL
Gas Correction Factor 1 (Pirani) C1
Analog Output Characteristic OC
1) Valid only for transducers with LCD display
The previous communication protocol version V1 will furthermore
be supported by all Smartline devices! Therefore all telegrams built
according to protocol version 1 can further be used.
VSP/VCP-RS485-200116
