52
Power consumption max. 2.5 W
0.8 W for relays and LCD
Output signal 0 - 10 VDC, min. 10 kΩ,
measuring range VSP: 1.5 - 8.5 VDC,
logarithmic
measuring range VCP: 2.2 - 8.5 VDC,
logarithmic
Serial interface RS485: 9.6 ... 115 kBd, 8 databit, 1 stopbit, no
parity
Switchpoints 2x relay, potential free
50 VAC / 2 A or 30 VDC / 2 A, max. 60 VA
Electrical connection Sub-D, 15-pole, male, lockable
Vacuum connection VSP63, VCP63: small flange DN16 ISO KF
VSP64, VCP64: conflat flange DN16 CF
Protection class IP 40 (IP 54)
Weight 190 g (VSP63)
VSP/VCP-RS485-200116
