ThyssenKrupp DAF 380 - 3 Technical Data; Dimensions

OPERATING MANUAL DAF290 TECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
3. Technical Data
3.1 Dimensions
Permissible axle load of the motor shaft: max. 60 kN
Braking torque: max. 1600 Nm
Moment of inertia (mot. + tract. sh.) / (rope pulley) 7 kgm² / 1.5 kgm²
Fig. 3.1
12
10-2012
Product has been
replaced
