OPERATING MANUAL DAF380 MAINTENANCE/SERVICE
ThyssenKrupp Aufzugswerke GmbH
7.2 Lubrication
Lubrication quantity on the front bearing (AS) of the motor shaft
Annual lubrication quantity
200 g
See Fig. 7.2
e.g. multipurpose grease F1
cartridge 400 gr
Code no. 60 300 27 90 0
The lubricator is positioned on the drive side behind the traction sheave.
See Fig. 7.2
The DAF380 requires otherwise no further relubrication.
• The second motor shaft roller bearing is filled-for-life with grease.
• The roller bearings for the machine base frame rope pulley also have
lifetime lubrication
e.g. multipurpose grease F1, can be obtained through
THYSSENKRUPP AUFZUGSWERKE GmbH
