Page #146 background imageLoading...
Page #146 background image
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN8 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN9
IN9
Logic Active-ON | Active-OFF
IN9 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN9 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN9 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN10
IN10
Logic Active-ON | Active-OFF
IN10 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN10 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN10 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN11
IN11
Logic Active-ON | Active-OFF
IN11 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN11 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN11 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN12
IN12
Logic Active-ON | Active-OFF
IN12 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN12 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN12 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
