Thytronic NA10 User Manual

Binary input IN13
IN13
Logic Active-ON | Active-OFF
IN13 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN13 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN13 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN14
IN14
Logic Active-ON | Active-OFF
IN14 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN14 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN14 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN15
IN15
Logic Active-ON | Active-OFF
IN15 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN15 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN15 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN16
IN16
Logic Active-ON | Active-OFF
IN16 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN16 tOFF
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
IN16 matching
Reset LEDs | Set profile | Fault trigger | Block2 IPh/
IE | Block2 IPh | Block2 IE | Block1 | TCS1 | TCS2 |
Trip ProtExt | Reset counters | Reset CB Monitor |
52a | 52b | Open CB | Close CB | Remote trip | Reset
on demand measures | None
Binary input IN17
IN17
Logic Active-ON | Active-OFF
IN17 tON
Value s
0.00 ... 9.99 step = 0.01
10.0 ... 100.0 step = 0.1
