SETTING AND COMMISSIONING
NA60_menuset5.ai
PREVIOUS SET MENU’
PREVIOUS PROFILE A MENU’
RS485
Protocol
Ethernet
Parameters
COMMUNICATION
Protocol MODBUS
Address 1
9600 baud
IP Address
200.1.2.222
SubNet Mask
255.255.255.0
Autonegotiation ON
NTP Synch. OFF
TEST
Test state: OFF
Stop test? >>
Start test? >>
Test K1 ? >>
Test K2 ? >>
Test K3 ? >>
Test K4 ? >>
Test K5 ? >>
Test K6 ? >>
SET
I* 0.1 In
I*enable ON
S<BLK1 OFF
tS< 1 s
S< 0.5
74CT Enable OFF
S<TR-K -
Relays S<
S<TR-L -
LEDs S<
CT SUPERVISION
74CT
RemTrip-K -
Relays
RemTrip -
LEDs
REMOTE
TRIPPING
PulseBLIN1-K -
Relays
PulseBLIN1-L -
LEDs
PILOT WIRE
DIAGNOSTIC
PulseBLOUT1 OFF
PulseBLIN1 OFF
N.ROL 12
tRoll 5 min
DEMAND
MEASURES
Periods
tFix 15 min
