NA11 - Manual - 02 - 2009
TECHNICAL DATA
Oscillography (DFR)
Format
COMTRADE
Recording mode
circular
Sampling rate
24 samples / power cycle
Set trigger:
Pre-trigger time
0.05...1.00 s (step 0.01 s)
Post-trigger time
0.05...60.00 s (step 0.05 s)
Set sampled channels:
Instantaneous currents i
L1
, i
L2
, i
L3
, i
E
[1]
Set analog channels:
Analog 1...Analog 12 Frequency, I
L1
, I
L2
, I
L3
, i
E
[2]
, I
EC
[3]
,
I
L1-2nd
, I
L2-2nd
, I
L3-2nd
, I
-2nd
/I
L
T1...T8
[4]
Set digital channels:
Digital 1...Digital 12 K1... K6, K7...K10,
IN1, IN2, IN3...IN42
[5]
PLC (Programmable Logic Controller)
reference standard IEC 61131-3
Language
[6]
IL (Instruction List)
Inputs:
Binary inputs IN1, IN2 on board
IN8...IN10 with MRI module
IN11...IN26 with one MID16 module
IN27...IN42 with two MID16 modules
Delayed binary inputs
[7]
IN1, IN2 on board
IN8...IN10 with MRI module
IN11...IN26 with one MID16 module
IN27...IN42 with two MID16 modu-
lesStart (all elements) Start I>, Start I>>,...etc
Trip (all elements) Trip I>, Trip I>>,...etc
Masures IL1, IL2,...etc
Temperature Pt10 0
Blocking inputs BLK2IN-Iph, BLK2IN-IE,..
Outputs:
Output relays: K11...K6 on board
K7...K10 with MRI module
LEDs START, TRIP, L1...L6 on board
L7...L10 with MRI module
Blocking outputs BLK2OUT-Iph, BLK2OUT-IE,...
Current converter DAC
Note 1 The measured residual current is available only for NA11 protection relays equipped with standard CTs sensor inputs
Note 2 The measured residual current is available only for NA11 protection relays equipped with standard CTs sensor inputs
Note 3 The computed residual current I
EC
(vector sum of the phase currents) is available for NA11 protection relays equipped with LPCT sensor in-
puts
Note 4 The temperature measuring is acquired by means of RTD probes Pt100 (eight Pt100 inputs with one MPT module); if the module is not available
the concerning measure is meaningless
Note 5 The K7...K10 and IN3...IN42 state is meaningful only when the corresponding I/O circuits are available (MRI and MID16 modules)
Note 6 With ThySetter V3.4.3 and IEC 61131-3 compiler V1.2.7, at presently only the IL language (Instruction List) is implemented;
other languages, according the IEC 61131 standard - ST (Structured Text), LD (Ladder Diagram), FBD (Function Block Diagram), SFC (Sequential
Functional Chart), will be available in the next future
Note 7 The state is acquired downstream the tON and tOFF timers
