APPENDIX
Description Parameter Unit Setting range
ThAL3 Operating time
Value
s 0 ... 100 step = 1
ThAL3 Alarm relays ThAL3-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL3 Alarm LEDs ThAL3-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Th>3 Trip
Th>3 Enable Th>3 Enable
OFF | ON
26 PT3 Trip threshold Th>3 ^C 0 ... 200 step = 1
Th>3 Operating time
Value
s 0 ... 100 step = 1
Th>3 Breaker failure Th>3BF
OFF | ON
Th>3 Trip relays Th>3-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>3 Trip LEDs Th>3-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
PT4 Probe
ThAL4 Alarm
ThAL4 Enable ThAL4 Enable
OFF | ON
26 PT4 Alarm threshold ThAL4 ^C 0 ... 200 step = 1
ThAL4 Operating time
Value
s 0 ... 100 step = 1
ThAL4 Alarm relays ThAL4-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL4 Alarm LEDs ThAL4-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Th>4 Trip
Th>4 Enable Th>4 Enable
OFF | ON
26 PT4 Trip threshold Th>4 ^C 0 ... 200 step = 1
Th>4 Operating time
Value
s 0 ... 100 step = 1
Th>4 Breaker failure Th>4BF
OFF | ON
Th>4 Trip relays Th>4-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>4 Trip LEDs Th>4-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
PT5 Probe
ThAL5 Alarm
ThAL5 Enable ThAL5 Enable
OFF | ON
26 PT5 Alarm threshold ThAL5 ^C 0 ... 200 step = 1
ThAL5 Operating time
Value
s 0 ... 100 step = 1
ThAL5 Alarm relays ThAL5-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
ThAL5 Alarm LEDs ThAL5-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
Th>5 Trip
Th>5 Enable Th>5 Enable
OFF | ON
26 PT5 Trip threshold Th>5 ^C 0 ... 200 step = 1
Th>5 Operating time
Value
s 0 ... 100 step = 1
Th>5 Breaker failure Th>5BF
OFF | ON
Th>5 Trip relays Th>5-K
K1 | K2 | K3 | K4 | K5 | K6 | K7 | K8 | K9 | K10
Th>5 Trip LEDs Th>5-L
START | TRIP | L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | L9
| L10
PT6 Probe
ThAL6 Alarm
ThAL6 Enable ThAL6 Enable
OFF | ON
26 PT6 Alarm threshold ThAL6 ^C 0 ... 200 step = 1
ThAL6 Operating time
Value
s 0 ... 100 step = 1
