APPENDIX
Description Parameter Unit Setting range
Switch 31
0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14
| 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 | 25 | 26
| 27 | 28 | 29 | 30 | 31 | 32 | 33 | 34 | 35 | 36 | 37 | 38
| 39 | 40 | 41 | 42 | 43 | 44 | 45 | 46 | 47 | 48 | 49 | 50
| 51 | 52 | 53 | 54 | 55 | 56 | 57 | 58 | 59 | 60 | 61 | 62
| 63 | 64 | 65 | 66 | 67 | 68 | 69 | 70 | 71 | 72 | 73 | 74
| 75 | 76 | 77 | 78 | 79 | 80 | 81 | 82 | 83 | 84 | 85 |
86 | 87 | 88 | 89 | 90 | 91 | 92 | 93 | 94 | 95 | 96 | 97
| 98 | 99
Switch 32
0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14
| 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 | 25 | 26
| 27 | 28 | 29 | 30 | 31 | 32 | 33 | 34 | 35 | 36 | 37 | 38
| 39 | 40 | 41 | 42 | 43 | 44 | 45 | 46 | 47 | 48 | 49 | 50
| 51 | 52 | 53 | 54 | 55 | 56 | 57 | 58 | 59 | 60 | 61 | 62
| 63 | 64 | 65 | 66 | 67 | 68 | 69 | 70 | 71 | 72 | 73 | 74
| 75 | 76 | 77 | 78 | 79 | 80 | 81 | 82 | 83 | 84 | 85 |
86 | 87 | 88 | 89 | 90 | 91 | 92 | 93 | 94 | 95 | 96 | 97
| 98 | 99
Timers
Timer 1
s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 2 s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 3
s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 4
s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 5
s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 6 s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 7
s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 8
s
0.00 ... 0.99 step = 0.01
1.0 ... 60.0 step = 0.1
Timer 9 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 10
s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 11
s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 12
s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 13 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 14
s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 15
s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 16 s
0.0 ... 59.9 step = 0.1
60 ... 299 step = 1
300 ... 3600 step = 10
Timer 17
s
0 ... 59 step = 1
60 ... 3540 step = 60
3600 ... 86400 step = 600
