FUNCTION CHARACTERISTICS
169
Oscillography
Trigger Setup
Following parameters, available inside the Set \ Oscillography \ Trigger Setup menu, are user-pro-
grammable:
Pre-triggertime
Post-triggertime
Elementpickuptrigger
Triggerfromoutputs
Triggerfromvirtualoutputs
Binaryinputtrigger
Triggerfrominputs1
Triggerfrominputs2
Triggerfromvirtualinputs
80%Bueralarm
Set sampled channels
The desired sampled quantities may be select inside the Set \ Oscillography \ Set sampled channels
menu.
iL1L
iL2L
iL3L
uE
iL1H
iL2H
iL3H
iE1
iL1T
iL2T
iL3T
iE2
u
iL1cL
iL1cH
iL1cT
iSL1
iDL1
iL2cL
iL2cH
iL2cT
iSL2
iDL2
iL3cL
iL3cH
iL3cT
iSL3
iDL3
Set analog channels
The desired sampled quantities may be select inside the Set \ Oscillography \ Set analog channels
menu.
Everyone of twelve analog channel may be associated to one of the selected measures.
Set digital channels
The desired digital quantities may be select inside the Set \ Oscillography \ Set digital channels menu.
Everyone of sixteen digital channel may be associated to one of the selected I/O signal.
Set digital channels from VOUT
The signals (VOUT1 ... VOUT32) may be select inside the Set \ Oscillography \ Set digital channels
from VOUT states menu (Binary 17...Binary 32).
Set digital channels from VIN
The signals (VIN1 ... VIN32) may be select inside the Set \ Oscillography \ Set digital channels from
VIN states menu (Binary 33...Binary 48).
XMR-T EQUIPMENT MANUAL
Ed. 2.9 - 02/2021
