Installation
18
A B C
The V-belt is then placed on the V-belt pulley below
the engine.
Start the engine.
WARNING:
Risk of injury! Do not reach into the
V-belt while it is in operation.
Read the operating instructions
provided by the lawn tractor manu-
facturer.
Check that the V-belt drive is running correctly
(V-belt pulley running true) – see the information
on installing the V-belt pulley. Check that the V-belt
is running freely and whether the edges of the
V-belt are in contact with the V-belt idler pulley,
optimising the alignment if necessary.
DANGER!
Switch the engine off again.
Keep a safe distance from hot sur-
faces.
Release the tension spring so that the V-belt tensioner
comes into operation.
CAUTION:
The spring is tensioned.
Risk of crushing.
CAUTION!
6XI¿FLHQW FOHDUDQFH PXVW EH PDLQ-
tained between the mower and V-belt
pulley.
