SECTION : F E ATU R E S
|
43
FE AT U R E S
GENERAL LAYOUTS
The General Layout illustrations show two models to represent a V-drive and
a direct drive. All of these components or accessories may not be included
on your Tigé boat.
DASH PANELS
The Dash Panel illustrations are used to help you identify the location of
switches, controls, ports, gauges and V-drive indicator. Your boat may not be
equipped with all of the features or options.
TIGÉ LINE DASH
1. Steering Tilt Lever
2. 12-Volt Ports
3. Ignition Key Switch, iPod
TM
/MP3 Port—Optional, Horn
4. Tigé Touch 2
5. Fuel Gauge
6. Tachometer
7. Speedometer
8. TAPS
2
Gauge
9. Shifter/Throttle Control Handle
10. Safety Lockout Ring (Shift Lockout)
11. Neutral Throttle Button
12. TAPS
2
Rocker Switch
13. Emergency Stop Switch
SWITCHES, CONTROLS, PORTS, GAUGES AND INDICATORS
Switches
The switches are fitted with LEDs, which will illuminate when power is
being supplied to the corresponding switch and its function. The switches
and components are protected by circuit breakers. If the component does
not function or switch does not illuminate, check the circuit breaker panel
located under the dash. Refer to Circuit Breaker Panel.
1
2
3
4
5
6
7
8
9
10
11
12
13
