LIST OF CONTENTS
Heading Page
INSTALLER GUIDE 3 - 17
OWNER GUIDE 18 - 24
1. SAFETY 5
2. APPLIANCE DATA AND EFFICIENCY 6
General information. 6
Efficiency. 6
3. UNPACKING 7
4. STOVE SET UP 8
Standard Legs and front cover (See figure 2). 8
Flue Collar, Deflector, Diverter Box and Flue Restrictor Plate. 8
Thermal switch. 9
Burner module. 10
5. GENERAL INSTALLATION REQUIREMENTS 10
Regulations, Standards and Law. 10
The Hearth. 11
Clearances. 11
Flue / Chimney. 11
Ventilation. 12
Location. 12
Propane gas. 12
Gas connection. 12
Securing the stove. 13
Fitting the ceramic fuel effect. 13
Fitting the fire bar. 13
6. OPERATING THE STOVE 13
Pre-lighting checks. 13
Lighting the burner. 13
Operating the burner. 13
Inlet pressure check. 14
Check for spillage. 14
Flame supervision and spillage monitoring system. 15
7. FINAL REVIEW AND SERVICING 15
Final Review. 15
Servicing. 16
Checking the aeration setting of the burner. 17
