Tiger Bengal - Step 4: Building Walls; Starting the First Log Layer

Pleaseretaininstruconsforfuturereference
Step 4:
BEGIN BUILDING WALLS
• Place1stlayeroflogsontheedgesofthebearers.Ensurehalflogsareputdownrst.Seeconstructdiagram
 forbuildorder.
NOTE: ADJUST TANALISED BEARERS TO SIT UNDER LOG JOINS.
• Measuretochecktheoorissquarebymeasuringthepointsshown.Ifallmeasurementsaretheequal,then
 yourbuildingissquare.Ifnot,manuallyadjustunlbothmeasurementsareequal.
• Screwlogsintotanalisedbearersusing3xS80perlog.(1xS80incenter,1xS80perendnotch)
• Forxingthroughnotches.(Detail D1)
• Forxingthroughhalflog.(Detail D2 & D3)
• Checkthatoorislevelusingaspiritlevel.
• Cuttanalisedbearersinlinewithoutsideofcabinlogsasshown.
D1 D2 D3
S80 S80 S80
09
1
4
231
2
4
3
