Step 4:
BEGIN BUILDING WALLS
• Place1stlayeroflogsontheedgesofthebearers.Ensurehalflogsareputdownrst.
 Seeconstructdiagramforbuildorder.
• Measurecornertocornerdiagonallytomakesurecabinoorissquare.Ifbothvaluesareequal,yourframeis
 square.Realigntheoorunlsquare.Donottrim.
• Screwlogsintotanalisedbearersusing3xS80perlog.(1xS80incentre,1xS80perendnotch)
• Forxingthroughnotches.
(Detail D1)
• Forxingthroughhalflog.(Detail D2 & D3)
• Checkthatoorislevelusingaspiritlevel.
D1 D2 D3
S80 S80 S80
1 2
12
09
