Tiger PDR-S - Part Names and Accessories

7
2
Part Names and Accessories
The numbers such as 98, 90, 80, 70
indicated in this instruction manual are
only approximate temperatures.
〈 Operation Panel 〉
〈 Power Cord 〉
Plug
( Plug into an outlet. )
Appliance plug
( Plug into the insert
slot of the unit. )
When the water is being boiled, bubbling
sounds can be heard from inside the
container. This is normal and does not
indicate a malfunction.
Sounds
Spout
Mesh filter
Prevents entry of foreign objects into
the pump.
Steam vent
Steam is emitted
when boiling.
Receptacle
Handle
Bottom
Turns 360°.
Water volume indicator
Open /close lever
Lid
Location
for discarding
hot water
Inside container
Lid gasket
Hinge
Maximum water
level
Keep water above
this level.
Water level line
Rell water
mark
Be sure the power cord is attached
when you turn the swivel bottom.
Caution
Display area
Keep warm lamp
Boil lamp
Energy Saving key
Unlock keyTemp.Set key
Re-Boil/Timer key
Unlock lamp
Dispense key
