TIMBERWOLF
TW 190TDHB
Serial No. Location
The serial number can be found
on the identification plate
located on the chassis beam.
Designed to chip solid wood material up to 190mm in diameter and
capable of chipping up to 6.5 tonnes of brushwood per hour.
DIMENSIONS - WITH FIXED TOWHEAD
2310 mm, (1300 mm with discharge removed)
1510m
m
TIMBERWOLF TW 190TDHB (FIXED TOWHEAD) SPECIFICATION
Engine type Kubota 4-cylinder turbo diesel
Maximum power 33kW (45hp)
Cooling method Water cooled
Overall weight 1020kg
Starting method Electric
Roller feed Twin series hydraulic motors
Maximum diameter material 190mm (7½")
Fuel capacity 50 litres
Hydraulic oil capacity 15 litres
Material processing capacity up to 6.5 tonnes/hr
Fuel type Diesel
The Timberwolf TW 190TDHB
TW 190TDHB
TIMBERWOLF
3990 mm with standard tow head (3385 mm with feed tray folded)
