1. General Information
These instructions should be read carefully
and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance,
ensure the mains supply to the time switch is
switched off and the circuit supply fuses are
removed or the circuit breaker turned off.
• It is recommended that a qualified electrician
is consulted or used for the installation of this
time switch and install in accordance with the
current IEE wiring and Building Regulations.
• Check that the total load on the circuit
including when this time switch is fitted
does not exceed the rating of the circuit cable,
fuse or circuit breaker.
3. Technical Specifications
• 230V AC 50 Hz
• This time switch is of class I construction
and must be earthed
• Switch Rating: 16A Resistive (3.68kW)
Immersion Heaters
• Switch Type: 16A relay
• Voltage free contact if wire link is removed
• Contact Type: Normally Open
• Manual Override: Permanent ON or OFF
• Boost Times: 1 or 2 hour
• Power Status
LED Indicator: Red
• Output LED
Indicator: Green
• 7 Day Time Period (7 Day, 5 + 2 Days
or Individual Day) – 4 ON/OFF switching
