Timeguard TRT034N - TRT034 N Front Panel Layout; Display Screen Symbols and Indicators; Front Panel Control Buttons

2
• Battery Backup: 7 Day, factory fitted rechargeable
(non-replaceable)
• Illumination: Blue LED illuminated on setting
for button surrounds and display
• CE Compliant
• Dimensions (H x W x D): 90 x 135 x 30mm
TRT034N Front View
The heating symbol will show
when heat is demanded
12hr am/pm
or 24hr clock
timer display
(illuminated
on setting)
Advance to next Programme,
ON/OFF override and copy function
Up down selection
buttons
1, 2 and 3 hour boost
function (illuminates
on setting)
Display light/Holiday
mode setting button
Flip down cover
conceals setting
buttons
