Timewatch TW6000DCLD - Introduction of the Gate Controller; Wiring Instructions

9
4. Introduction of the gate controller
Motor
source
Function button
status lamp
Definition of wiring
terminal
4.1 Wiring instructions:
1. The start, stop, off and public are the gate control signal input, which can be
connected to three manual buttons, and the camera opening input is connected to the
start and public, regardless of sequence.Close the gate input access to the off-gate
and public, regardless of order.
