EN
23
OVERVIEW
Note:
Accessories may vary between markets. If you
require more accessories, please go to
www.tineco.com or store.tineco.com.
1
WiFi/Mute/Language Switch Button
2 Back Carry Handle
3 Cord Wrap
4 Dirty Water Tank Release Pedal
5 Recline Pedal
6 AUTO/MAX/DRY Mode
7 Power On/Off
8 Tube
9 Digital Display
10 Clean Water Tank Handle
11 Clean Water Tank (CWT)
12 Dirty Water Tank Handle
13 Dirty Water Tank (DWT)
14 Brush Roller Cover Release Button
15 Hose Connection Port Cover
16 Brush Roller Cover
17 Humidity Sensor
18 Carpet Deodorizing & Cleaning Solution
19 Cleaning Tool
20 2 in 1 Nozzle
21 Sponge Filter
22 Brush Cover Scraper
23 Accessory Hose
24 Accessory Hose Icon
25 DWT Full or Blocked
26
Dirt Monitoring Loop
(Blue to red according to the dirt amount)
27 AUTO Mode
28 CWT Empty
29 Brush Roller Tangled Indicator
30 Dry Degree Indicator
31 Tineco Logo
32 WiFi Indicator
33 Water Spray Volume Indicator
Fig.A
ASSEMBLY
How to Assemble/Disassemble
• To assemble the handle, insert it into the
appliance until you hear a click.
Fig.B-1
• In the event that the handle need to be
disassembled, press the spring to release the
handle with a tool (like a screwdriver) and lift
the released handle from the appliance.
Fig.B-2
• Wrap the power cord around the cord hooks
for convenient storage.
Fig.B-3
Clean Water Tank
• Press the CWT handle to remove it.
Fig.B-4
• Open the tank cap, add two bottle caps of
solution to the CWT then ll with tap water to
the Max line and tightly close the cap.
Fig.B-5
Note:
Only use water under 140°F/60°C.
DO NOT USE HOT WATER.
• Install the Clean Water Tank into the appliance.
You should hear a “Click” if done correctly.
Fig.B-6
Dirty Water Tank
• Install the Dirty Water Tank into the appliance.
You should hear a “Click” if done correctly.
Fig.B-7
Accessory Hose & 2 in 1 Nozzle
• Choose suitable brush head according to the
usage scenario.
Fig.B-8
• Pull it up to uncover the accessory connection
port.
Fig.B-9
To Next Page
