Tineco S10 Series User Manual

EN
9
Assembly
Tube Installation
Insert tube. Press the release button to remove the tube.
Brush Installation
Insert the power brush. Press the release button to remove the power
brush.
Dustbin Installation
①
②
To clean the dustbin more thoroughly, press
the dustbin release button to detach from the
appliance.
When re-attaching the dustbin, hold on an angle
and slot the top of the dustbin into the hook
on the main body. Push upwards until the hook
is xed into the slot on the dustbin and then it
clicks back into place.

Tineco S10 Series Specifications

General

Battery Type	Lithium-Ion
Type	Stick Vacuum
Run Time	Up to 40 minutes
Dustbin Capacity	0.6L
Filtration System	HEPA filtration
Motor	Digital motor
Accessories	Motorized floor brush, crevice tool, combination tool, charging dock
Charge Time	4 hours
