8
AC/DC Current Measurement
1) Select the rotary switch to the appropriate current measurement function & range.
2) Insert black test lead banana plug into the negative COM input terminal.
3) To perform current measurements less than 200mA insert the red test lead banana plug into
the mA Input terminal or for current measurement between 200mA to 10A insert the red test
lead banana plug into 10A input terminal
4) Disconnect the circuit under test then connect the test leads in series with the circuit.
5) Turn the power on and read the measurement value displayed.
If OL (Over Limit) is displayed, increase the measurement range / function.
Diode Test
1. Set the rotary switch to the “ position.
2. Connect the black test lead to the "COM" terminal and the red test lead to the "VΩ:" input terminal.
3. Pres the “SEL” button to select the diode function (If required)
4. Connect the test leads to the diode, test both the “Forward Bias & Reverse Bias” of the diode under test.
Open circuit measurements will be indicated as OL on the display,
Continuity Indication / Buzzer Test
1. Set the rotary switch to the “ ” position.
2. Connect the black test lead to the "COM" terminal and the red test lead to the "VΩ:" input terminal.
3. Pres the “SEL” button to select the continuity function (If required)
4. Connect test leads to the circuit under test.
5. Measurement will be displayed and the audible indicator will sound, when measurements are under 70.
