Titan 3PTTRIM User Manual

18
Ref#
Drawing No.
Description
Qty
1
TS600-02000
Base
1
2
9604-30305
Single Row Taper Roller Bearing
2
3
TS600-00003
Spacer B
1
4
TS600-00004
Articulating Bracket A
1
5
TS600-00005
Articulating Bracket B
1
6
9101-10040-DX8.8
Hex Bolt M10x40
8
7
9301-1000-DX
Flat Washer Ø10
8
8
TS6000-03000
Gearbox Fixed Frame
2
9
9215-10000-DX8.8
Hex Flange Lock Nut M10
35
10
TS600-01000
3-Point Bracket
1
11
TS600-00006
Nylon Sleeve
2
12
TS600-00007
Fixing Ring
1
13
T400-40000-DX
Drive Pin
4
14
N800-00003-DX
Hitch Pin
2
15
9306-22000-DX
Lock Washer Ø22
2
16
9301-22000-DX
Flat Washer Ø22
2
17
9206-22000-DC
Hex Nut M22
2
18
9101-10040-8.8Q
Hex Bolt M10x40
1
19
9101-18240-DX8.8
Hex Bolt M8x240
1
20
9201-18000-DX
Hex Nut M8
1
21
SMP700-06000
PTO Shaft
1
22
TS600-06000
Linch Pin
1
23
TS600-00009
Frame
1
24
TS600-09000
Pivot Support Shaft
1
25
TS600-08000
Gearbox
1
26
TS600-04000
Gearbox Guard
1
27
TS600-04002
Bushing
2
28
9101-10180-DX8.8
Hex Bolt M10x180
2
29
9302-10000-DX
Big Flat Washer Ø10
21
30
9208-10000-8.8DX
Wing Nut M10
1
Parts Drawing & Parts List

Titan 3PTTRIM Specifications

General

Brand	Titan
Model	3PTTRIM
Category	Trimmer
Language	English
