Titan 3PTTRIM - Page 19

19
Ref#
Drawing No.
Description
Qty
31
9101-10125-8.8DX
Hex Bolt M10x125
2
32
Flat Key 8x7x32
2
33
9101-10025-DX
Hex Bolt M10x25
22
34
TS600-00010
Spring Holder Base
1
35
TS600-13000
Belt Adjustment Plate
1
36
9101-10065-8.8Q
Hex Bolt M10x65
1
37
9206-10000-DX8.8
Hex Lock Nut M10
38
TS600-00008
Pulley Ø190
1
39
TS600-07000
Rotor Bearing
1
40
9603-6203-2RS
Deep Groove Ball Bearing 6203-2RS
2
41
9309-40000-FH
Circlip for Hole Ø40
1
42
TS600-00011
Shaft
1
43
TS600-00002
Pulley Ø77
1
44
Flat Key 5x5x20
1
45
9302-06000-DX
Big Flat Washer Ø6
10
46
9101-01016-DX8.8
Hex Bolt M6x16
10
47
9302-08000-DX
Big Flat Washer Ø8
4
48
6215-08000-DX8.8
Hex Flange Lock Nut M8
10
49
TS600-12000-DX
Wheel Axle Spacer
1
50
9010-08020
Hex Bolt M8x20
6
51
TS600-00012
Adapter
1
52
TS600-00013
Spacer
1
53
TS600-00014
Anti Wrap Can
1
54
TS600-00015
Briquetting A
1
55
TS600-00016
Molded Spacer
1
56
TS600-00017
Plastic Spherical Cap
1
57
TS600-00018
Briquetting B
1
58
TS600-00019
Briquetting C
1
59
TS600-11000
Barb
4
60
TS600-00021
Pressure Spring
4
Parts Drawing & Parts List
