Titan 3PTTRIM User Manual

20
Ref#
Drawing No.
Description
Qty
61
9103-05024-DX8.8
Hex Socket Countersunk Head Screw M5x24
4
62
TS600-00001
Hex Bolt M8x25
1
63
TS600-06000
Deflector Guard
1
64
9101-08030-DX8.8
Hex Bolt M8x30
4
65
TS600-00022
Connecting Plate
2
66
TS600-05000
Wheel Stand
1
67
9701-06000
Oil Cup
1
68
TS600-00023
Nylon Bushing
2
69
TS600-10000
Wheel Caster
1
70
TS600-00024
Spacer
6
71
TS600-14000
Pneumatic Wheel
1
72
9404-04040-DX
Cotter Pin 4x40
2
73
TS600-00025
Cutting Cord
2
74
TS600-00026
Nylon Loop
2
75
V-Belt A-2565
1
76
TS600-00020
Belt Cover
1
77
TS600-12000
Small Belt Cover
1
78
TS600-15000
Springback Assembly
1
79
9101-12055-DX8.8
Hex Bolt M12x55
1
80
9206-12000-DX
Nylon Lock Nut M12
1
81
9312-25000-FH
Wire Snap Ring for Shaft Ø25
1
82
LSP25-00020-FH
Hex Slotted Thin Nut M20x1.5
1
83
939903-08000-DX
Big Flat Washer Ø8
1
84
9010-08015
Hex Bolt M8x15
1
85
N800-00004-DX
Hitch Pin
2
Parts Drawing & Parts List
