Titan 540ix - Fluid Section Assembly

22 © Titan Tool Inc. All rights reserved.
Fluid Section Assembly (Skid P/N 704-538, High Rider 704-571)
23
24
25
26
27
28
29
30
9
8
11
12
10
7
1
2
3
4
5
14
13
15
16
17
18
19
6
21
22
2
0
Install upper packing
with raised lip and
O-ring facing down.
O-Ring
R
aised Lip
Install lower packing
with the beveled
edge facing up.
Beveled Edge
NOTE:
When using “hot” solvents, replace Viton valve
stem o-ring (item 27) with optional T
eflon valve
stem o-ring (P/N 700-897). Install using o-ring
replacement tool (P/N 700-890).
