Volume Pumped Screen
The Volume Pumped screen
shows the total number of
gallons or liters sprayed by the
sprayer.
To select the Volume Pumped
screen, press the #4 key.
Job Volume Screen
The Job Volume screen allows
the user to reset a gallon
counter to track usage on
specific jobs.
T
o select the Job Volume
s
creen, press the #4 key.
Unit Serial # Screen
The Unit Serial # screen
shows the sprayers serial
number.
To select the Unit Serial #
screen, press the #4 key.
Timers Screen
The Timers screen shows the
total time the sprayer has been
turned on as well as the total
time the sprayer has been running (pumping).
To select the Timers screen,
press the #4 key.
Job Timers Screen
The Job Timers screen allows
the user to reset the “ON
TIME” and “RUN TIME” to
track time on specific jobs.
To select the Job TImers
screen, press the #4 key. The
screen will toggle between the
timers and a screen that allows the user to reset the timers.
Service Time Screen
The Service Time screen
allows the user to set a service
time interval (in hours). Below
the set time, the screens shows the current amount of hours
on the sprayer
.
To select the Service TImer screen, press the
#4 key
.
The screen will toggle between
the service hours and a screen
that allows the user to change
the service time interval.
When the service time interval is set and met by the run hours,
the display will toggle between the "Main screen" and a
"Service Required" screen at sprayer startup. T
o stop the
toggling, scroll to the "Service T
ime" screen and either set a
new service time interval or set the service time to "0".
Pressure Screen
The Pressure screen allows
the user to see the current set
point pressure as well as the
actual working pressure.
To select the Pressure screen,
press the #4 key. This screen
is also the Main Screen.
SET PSI 3000
ACTUAL PSI 2950
SERVICE @ XXXHR
RUN HOURS XX
SERVICE TIME
SELECT-4 MENU-1
ON TIME XXXXX:XX
RUN TIME XXXX:XX
JOB TIMERS
SELECT-4 MENU-1
ON TIME XXXXX:XX
RUN TIME XXXX:XX
SER # XXXXXXXXXX
PRESS 1 FOR MENU
UNIT SERIAL #
SELECT-4 MENU-1
JOB GALLONS XXXX
MENU-1 RESET-3
JOB VOLUME
SELECT-4 MENU-1
GALLONS XXXXXX
PRESS 1 FOR MENU
VOLUME PUMPED
SELECT-4 MENU-1
© Titan Tool Inc. All rights reserved. 7
Security Code Screen
The Security Code screen
allows the user to set a four
digit security code to prevent
unauthorized use of the sprayer. If a security code has been
set, the control system display will ask for the code at startup.
If the correct code is entered, the display will show the Main
Screen and the sprayer will operate. If the wrong code is
entered, the display will continue to ask for the correct code
and the sprayer will be disabled. To set or change the security
code, press the #2 key.
E
nter the old security code
number to access the screen
that allows the code change.
If the wrong code is entered, the display will continue to ask
for the correct code and the security code cannot be changed.
Enter the new security code.
Once the new code is entered,
the display will automatically
ask that the new code be re-entered for verification. If the
same new code is re-entered, the display will confirm that the
new code has been accepted and return to the Main Screen.
If the new code is re-entered incorrectly, the display will return
to the “Enter New Code Number” screen and the process will
repeat.
Prime Screen
The Prime screen appears
when the pressure control
knob is set at the “Min” setting
in the yellow zone.
Pulse Clean Screen
The Pulse Clean screen
appears when the pressure
control knob is set at the
PULSE CLEAN position in the red zone and the
PRIME/SPRAY valve is in the PRIME position.
NOTE: If there is no action at any menu screen for 30
seconds, the display will go back to the Main
Screen.
PULSE CLEAN
ACTUAL PSI XXXX
NOTE: To inactivate the X-Lock security function,
enter “1111” at the “Enter New Code Number”
screen (this is the default code that leaves the
sprayer unlocked). As a result, the Main
Screen will appear at sprayer startup.
NOTE: If the sprayer is new, no security code is set
and the Main Screen will appear at startup.
Also, when setting a security code for the first
time, the “Enter Old Code Number” screen will
not appear.
SECURITY CODE
SELECT-4 MENU-1
