Titan T500 User Manual

8
OPERATION
Fig. 3
Bare Floor Cleaning
Your vacuum is equipped with a
squeegee on the bottom of the vacuum
to improve its effectiveness in cleaning
bare floors (Fig. 1).
Vacuuming Under Furniture
Your vacuum will lay flat on the floor for
effective cleaning under beds and tables.
• Press the Handle Release Pedal once
for normal vacuum cleaning (Fig. 2).
• Continue to lower the handle to enable
the vacuum to lay flat on the floor
(Fig.3).
