7
On/Off Switch
• Turn the switch on to use the vacuum.
If the vacuum doesn’t turn on, check that
the battery is charged (see page 6).
• Always unplug the charger from the
charge point before use.
Edge Cleaning
The edge cleaning feature provides
improved cleaning near walls and
stationary furniture. For maximum
edge cleaning, place the left side of
the nozzle, from the user’s perspective,
against the wall or stationary furniture
(Fig 2).
Automatic Carpet
Height Adjustment
Your vacuum is designed with an
automatic self-adjusting nozzle.
No manual adjustments are required.
The height of the nozzle automatically
adjusts to the flooring surface. This
self-adjusting feature allows the nozzle
to float evenly over all flooring surfaces.
