TTB579PLN by TITAN
Getting started...
GB
04
Your product
Your product
1. ON/Off switch
2. Motor overload switch
3. Rubber (anti vibration) foot
4. Thickneser extension rail
5. Cut depth control knob (planer mode)
6. Adjustable (in-feed) table (planer mode)
7. Extraction port adapter
8. Guide fence
9. Blade (cutter) guard
10. Blade guard locking knob
11. Height adjusting handle
(thicknesser mode)
12. Blade guard angle locking screw
13. Fixed (out-feed) table (planer mode)
14. Blade guard arm assembly
15. Safety interlock switch
16. 45° Fence angle stop
17. Angle pointer
18. 90° Fence angle stop
19. Angle guide
20. Fence angle lock handle
21. Cable clips
IE
8
20
19
18
21
16
1
2
7
13
15
7
17
3
4
5
6
12
8
101114 9
