25
TTB579PLN by TITAN
Product functions
In more detail…
GB
IE
parallel with the in-feed table for the whole pass.
> Slowly push the workpiece forward (over the cutter-block).
Caution: It is much safer (particularly when using a thin / small workpiece)
to use the supplied push blocks (34).
> Repeat these steps until the correct amount of material has been removed.
Fig. 24
Fig. 25 Fig. 26
NOTE: Keep firm and even pressure on the workpiece as it passes
over the in-feed table and continue pushing forward until the back
of the workpiece passes the cutter-block.
1) Setting the blade guard
Thicknesser mode:
> Loosen the blade guard locking knob (10) (turn clockwise). (Fig. 25)
> Slide the blade guard (9) out as far as it will go. (Fig. 26)
10
9
34
