Toa A-906MK2 - 10. DIMENSIONAL DIAGRAMS; 10.1. A-903 MK2 Dimensions; 10.2. A-906 MK2, A-912 MK2 Dimensions

SIGNAL NORMAL
PROTECT
PEAK
POWER
ON
OFF
MASTER
INPUT 8INPUT 7INPUT 6INPUT 5INPUT 4INPUT 3INPUT 2INPUT 1
TREBLE TONE DEFEAT
OFF ON
BASS LOW CUT
OFF ON
INPUT 8 INPUT 7 INPUT 6 INPUT 5 INPUT 4 INPUT 3 INPUT 2 INPUT 1
SIGNAL NORMAL
PROTECT
PEAK
POWER
ON
OFF
MASTER
INPUT 8INPUT 7INPUT 6INPUT 5INPUT 4INPUT 3INPUT 2INPUT 1
TREBLE TONE DEFEAT
OFF ON
BASS LOW CUT
OFF ON
INPUT 8 INPUT 7 INPUT 6 INPUT 5 INPUT 4 INPUT 3 INPUT 2 INPUT 1
280 (11.02)17 (0.67) 318 (12.52)
Unit: mm (inches)
Unit: mm (inches)
76.2 (3)
88.4 (3.48)
99.1 (3.9)
466 (18.35)
420 (16.54)
482.6 (19)
466 (18.35)
420 (16.54)
482.6 (19)
320 (12.6)17 (0.67) 358 (14.09)
76.2 (3)
88.4 (3.48)
99.1 (3.9)
14
10. DIMENSIONAL DIAGRAMS
10.1. A-903MK2
10.2. A-906MK2, A-912MK2
