13. SPECIFICATIONS
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Front grille ............................................................ 1
Tile bridge ............................................................ 1
Safety wire (approx. 60 cm or 23
5
/8") .................. 1
Paper pattern ....................................................... 1
F-2322CU2 F-2352CU2
Bass reflex type
30 W (High Impedance)
Continuous pink noise: 60 W (8 Ω), 30 W (16 Ω)
70 V line: 170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
25 V line: 170 Ω (3.7 W), 330 Ω (1.9 W), 1 kΩ (0.6 W), 3.3 kΩ (0.2 W),
10 kΩ (0.06 W)
16 Ω, 8 Ω
90 dB (1 W, 1 m)
70 – 20,000 Hz
12 cm (5") cone-type High frequency: Balanced dome-type
Low frequency: 12 cm (5") cone-type
UL1480 (UEAY), UL2043, CAN/CSA C22.2 No.205 (UEAY7)
ø200 mm (7
7
/8")
Maximum ceiling thickness: 37 mm (1
29
/64")
Removable locking connector with screw-down terminals
(2 input terminals and 2 bridge terminals)
Solid copper wire: ø1.0 – ø1.6 mm (equivalent to AWG 18 – 14)
Stranded copper wire: 0.75 – 2.5 mm
2
(equivalent to AWG 18 – 14)
Enclosure: Steel plate, plating
Baffle: Fire-resistant ABS resin (resin material grade: UL-94 V-0 or
its equivalent), black
Rim: Fire-resistant ABS resin (resin material grade: UL-94 V-0 or
its equivalent), white, paint
Punched net: Steel plate, white, paint
ø230 mm (9
1
/16") x Depth 209 mm (8
15
/64") ø230 mm (9
1
/16") x Depth 238 mm (9
3
/8")
4.3 kg (including mounting accessories)
Model No.
Enclosure
Rated Input
Power Handling Capacity
Impedance
Sound Pressure Level
Frequency Response
Speaker Component
UL Code
Mounting Hole
Input Terminal
Usable Cable
Finish
Dimensions
Weight
533-06-147-5A
